TRA3

Independent wall for musical premises or sound emission >90 dB

  • Acoustic Insulation: High-density bituminous sheet / Cross-linked polyethylene with acoustic membrane and rock wool
Share

Acoustic Insulation

MAD4

Acoustic Insulation

SONODAN PLUS AUTOADHESIVO.

Downloads
Datasheet
BIM
Noise protection
9574TRA3

Independent wall

Advantages

  • Airborne noise insulation achieved at R’A,tr > 67 dBA, giving sufficient isolation to meet the levels of emission in common areas.
  • The plastering ensures the impermeability of the wall and its acoustic tightness.
  • Combined absorption into cavity at low, medium and high frequencies.
  • Insulation to low frequency impulse noise.
  • The resonance frequencies of the system are shifted to less audible frequencies.
  • The acoustic membrane improves the insulation at low frequencies of the plasterboard system.
  • Its acoustic insulation capacity can be improved by increasing the thickness of the chamber.
  • Light system providing better results, with low thickness and faster execution.

    • Application

  • Machine rooms in residential buildings: hotels, hospitals, teachers and offices
  • Music venues: pubs, karaokes, discos, party rooms, wedding halls...
  • Music recording studios

    • Graph

    Technical Requirements

    FunctionProductDescriptionPropertyValue
    Acoustic insulation at impulse noise of low, medium and high frequenciesSONODAN®
    PLUS
    Autoadhesivo    		Panel composed of a first layer of cross-linked polyethylene foam and high-density membrane and a second layer of high-density membrane and rock woolRABetween 52-65 dBA
    Anti-resonant acoustic insulationM.A.D.® 4 /
    M.A.D.® 6    		High-density membraneΔRA between rigid elements4 dBA /
    6 dBA

    Recommendations

    Note: This sheet is included in an acoustic box-in-box system.
    * M.A.D.® 6 for emission levels above 105 dB.

    Unit of Work

    Multilayer insulation for low, medium and high frequencies of 40 mm thickness, SONODAN® PLUS SELF-ADHESIVE mechanically fixed to the plastered wall with insulation fixings of 40; 50 mm plasterboard structure, 12.5 plasterboard placement fixed to the structure by means screw and sealed; 4 mm thick Danosa Acoustic Membrane, M.A.D.® 4 stapled to the first board; fixing to the structure of the second laminated plasterboard of 12.5 mm thickness by means screws, fully sealed and installed, ready to apply the finishing.

    System documentation download TRA3

    You must enter your details to download

    Personal data

    Project data

    Installation video
