DURADAN REINFORCEMENT MESH
Fibre glass reinforcement mesh
Product variations:
A fibre glass reinforcement mesh for use with duradan structural hot melt waterproofing systems.
Advantages & Benefits
- Good resistance to alkalinity.
Instruction for Use
- Substrate should be dry and clean from grease, dirt, debris or any other contaminants.
- Loose-lay onto substrate. (if required, spot bond with DURADAN ELAST 110/50 hot melt liquid to tack reinforcement mesh into position).
- Side and head overlaps should be 100 mm and there should be no gaps between adjacent sheets.
Handling, storage and preservation
- Rolls should be stored upright in a cool, dry area inside original packaging. Products are supplied on a cardboard tubing.
Notice
- The information contained in this document and any other advice provided, are given in good faith, based on DANOSA's current knowledge and experience when products are properly stored, handled and applied, in normal situations and in accordance with the recommendations of DANOSA. The information applies only to the application (s) and the product (s) to which reference is expressly made. In case of changes in the parameters of the application, or in case of a different application, consult the DANOSA Technical Service before using the DANOSA products. The information contained herein does not exonerate the responsibility of the building agents to test the products for the application and intended use, as well as their correct application in accordance with current legal regulations. The product images used in our communications are indicative and may differ slightly in color and aesthetic appearance in relation to the final product.Orders are accepted in accordance with the terms of our current General Sales Conditions.DANOSA reserves the right to modify, without prior notice, the data reflected in this documentation.Website: www.danosa.com E-mail: info@danosa.com Telephone: +34 949 88 82 10
Presentation
- Length (cm): 5000
- Width (cm): 100
- Mesh size (mm): 5.0 x 5.0
- Colour: White
- Product code: 320165
Technical Data
| Concept | Value | Standard |
|---|---|---|
| Mass per unit area (nominal) (kg/m²) | 145 | - |
| Longitudinal tensile strength (N / 5cm) | 1500 | - |
| Transverse tensile strength (N / 5cm) | 2000 | - |
